E8018-B2
AWS A5.1 E8018-B2
ASME SFA 5.1 E8018-B2
8018-B2 is Cr-Mo covered electrodes commonly used in maintenance and fabrication of 1/2 % Mo and 1/2 -1.25 % Cr where base metals in the power / boiler piping and equipment may be found. 8018-B2 can be used for base metal such as A335-P2, P11, P12, A119-T11, A301-B, A217-WC6, and A182-F11. The low hydrogen potassium, iron powder covering has high deposition with good smooth arc, low spatter and easy slag removal. Preheat of 300-500° F and postheat of 1250-1350°F are often found with this alloy.
TYPICAL WELD METAL CHEMISTRY (%)
C | 0.06 |
Mn | 0.70 |
Si | 0.610 |
S | 0.010 |
Mo | 0.55 |
TYPICAL MECHANICAL PROPERTIES OF WELD DEPOSIT
(As welded)
Yield strength (psi) | 86,000 |
Tensile strength (psi) | 97,000 |
Elongation in 2" (%) | 25% |
Charpy V-notch at - 20 degrees | 30 ft lbs |
