Eagle Arc BW 799 (ER71T-1/4)

AWS A5.20 CLASS E71T-1/4

EAGLE ARC 799 is a baked flux cored wire designed for single or multi pass welding having a smooth arc transfer, low spatter, flat to slightly convex bead contour, with a high deposition rate and easily removal slag. This all-position baked wire has excellent feeding and low fume generation using 100% CO2 or mixed gas making it a good choice for mild steel and higher strengths steels.

Applications:

The baked process ensures the removal of moisture and may reduce operating temperature along with less wear and drag in the feeding systems. Bridge & offshore structures, ship building, earth moving and all general fabrication requirement with excellent operator appeal.

TYPICAL WELD METAL CHEMISTRY
(% – tested with 100% CO2 Shield Gas)

C

0.03

Mn

1.45

Si

0.50

P

0.011

S

0.010

TYPICAL MECHANICAL PROPERTIES
OF WELD DEPOSIT
(As welded – tested with 100% CO2 Shield Gas)

Tensile strength (psi)

88,194 psi

Elongation in 2" (%)

28.1%

Yield point (psi)

80,986 psi

Charpy V-Notch impact

62.7 ft lbs
